0603貼片保險絲
Description
06 100 Series are the fuses set the industry standard for performance, reliability and
quality. The solder-free design provides excellent on-off and temperature cycling
characteristics during use and also makes our SMD fuses more heat and shock
tolerant than typical subminiature fuses.
Electrical Characteristics
Rated Current 1.0In 2.0In
250mA~8A 4 hour minimum 60 sec maximum
Features
? High inrush current withstanding capability
? Compatible with reflow and wave solder
? Excellent environmental integrity
? One time positive disconnect
? Lead Free and Halogen free material
Specifications
Specification
|
|
Part No. |
|
Rated Voltage DC |
|
Rated Current (A) |
|
Breaking Capacity (A) 1 |
|
Typical Cold. Resistance (mOhms) 2 |
|
Typical Voltage Drop (mV) |
|
Typical Pre- Arcing I2t (A2Sec) 3 |
|
Alpha Mark |
06 100.0.25 0.250 50A 3250 893 0.00042 D
06 100.0.375 0.375 50A 1310 587 0.00093 E 06 100.0.5 0.500 50A 1070 582 0.0020 F
63V
06 100.0.75 0.750 50A 470 427 0.0092 G 06 100.1 1 50A 300 345 0.011 B
06 100.1.5 1.5 50A 150 270 0.045 H
06 100.2 2 50A 72 160 0.115 K
06 100.2.5 32V 2.5 50A 52 145 0.14 L
06 100.3 3 50A 35 130 0.21 O
06 100.3.5 3.5 50A 23.8 130 0.55 R
06 100.4 - 4 50A 21 120 0.52 S
06 100.5 5 50A 14 110 1.2 T
06 100.6 6 50A 8 110 1.7 V
06 100.7 7 50A 5.6 80 2.3 X
06 100.8 8 50A 3.5 75 3.0 Z
* DC Interrupting Rating (Measured at rated voltage, time constant of less than 50 microseconds, battery source)
* DC Cold Resistance are measured at <10% of rated current in ambient temperature of 25degrees
* Typical Pre-arching I2t are measured at 10In Current
** For 1A-5A, the color of glass coating is Green; for others, it’s Blue.
